| Model | Out voltage | Output Current | Output Power |
|---|---|---|---|
| T-200-1000 | 0-200Vdc | 5A | 1000W |
| T-220-1000 | 0-220Vdc | 4.5A | 1000W |
| T-250-1000 | 0-250Vdc | 4A | 1000W |
| T-300-1000 | 0-300Vdc | 3.3A | 1000W |
| T-400-1000 | 0-400Vdc | 2.5A | 1000W |
| T-500-1000 | 0-500Vdc | 2A | 1000W |
| T-600-1000 | 0-600Vdc | 1.7A | 1000W |
| Model | T-200-1000 | T-220-1000 | T-250-1000 | T-300-1000 | T-400-1000 | T-500-1000 | T-600-1000 |
|---|---|---|---|---|---|---|---|
| Output Voltage | 0-200Vdc | 0-220Vdc | 0-250Vdc | 0-300Vdc | 0-400Vdc | 0-500Vdc | 0-600Vdc |
| Output voltage tolerance | 1% | 1% | 1% | 1% | 1% | 1% | 1% |
| Rated output current | 5A | 4.5A | 4A | 3.3A | 2.5A | 2A | 1.7A |
| Wave and noise | 150mV P-P | 150mV P-P | 160mV P-P | 160mV P-P | 180mV P-P | 200mV P-P | 200mV P-P |
| DC output power | 1000W | 1000W | 1000W | 1000W | 1000W | 1000W | 1000W |
| Efficiency | 85% | 85% | 87% | 87% | 89% | 91% | 91% |
| Adjustable range for dc voltage | The output voltage is 100% adjustable through the potentiometer |
| AC input voltage range | AC174-264VAC 50Hz |
| Input current | 230V/6 A |
| AC in lash current | Cold start current 80A/230V |
| leakage current | ≤1.5mA 230V AC |
| Overload protection | Load more than 110%~120% switch to constant current mode |
| Overvoltage protection | ≥15% of output voltage |
| Setup/Rise/ Hold time | 200ms / 100ms / 20ms |
| Vibration | 10-50Hz, 2G 10 minutes/cycle X, Y, Z axis each 60 minutes |
| Withstand voltage | Input to shell 1500V/3mA AC | Input to output 1500V/3mA AC | Input to output 500V/3mA AC |
| Net weight | 1360g |
| Dimension | 262mm*105mm*65mm (L*W*H) |
1. Guarantee time: 12 Months.
2. Return policy: We can exchange goods if there is a quality problem.
1. Excellent products (unique design, strict quality control).
2. Great service (OEM, ODM, after-sales services, fast delivery).
3. Professional business consultation.
Low MOQ, 1 set for sample testing is available.
Yes, the output voltage and output current are adjustable, featuring a constant voltage and constant current design.
Yes, other output voltage specifications can be customized based on your requirements.
It features multiple safety protections, including short circuit, overload, and overvoltage protection.
